- Kamera
- Image Sensor2 MP CMOS
- Signal SystemPAL/NTSC
- Resolution1920 (H) × 1080 (V)
- Frame RateTVI: 1080p@25fps, 1080p@30fps
- Min. Illumination0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Lens2.8 mm, 3.6 mm fixed focal lens
- Field Of View
2.8 mm, horizontal FOV: 106.4°, vertical FOV: 57.9°, diagonal FOV: 124.6°
3.6 mm, horizontal FOV: 81.3°, vertical FOV: 44.7°, diagonal FOV: 94.5°
- Lens MountM12
- Light AlarmFlashing Light Alarm (White Light);Solid Light Alarm (White Light)
- Day & NightIR Cut Filter
- WDR (Wide Dynamic Range)Digital WDR
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
- Image
- White LightAuto/Off
- Image ModeSTD/HIGH-SAT
- AGCYes
- Day/Night ModeAuto/Color/BW (Black and White)
- White BalanceAuto/Manual
- AE (Auto Exposure) ModeGlobal;HLC;BLC;DWDR
- Noise Reduction2D DNR
- LanguageEnglish
- FunctionSharpness;Smart IR;Mirror;Brightness
- Interface
- Video Output1 HD analog output
- General
- Operating Conditions-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensing)
- Power Supply
12VDC ± 25%
*You are recommended to use one power adapter to supply the power for one camera.
- ConsumptionMax. 3.6 W
- Protection LevelIP66
- MaterialMetal
- IR RangeUp to 20 m
- White Light RangeUp to 20 m
- PIR RangeAngle: 110°, Range: 11 m
- CommunicationHIKVISION-C
- Dimension166.7 mm × 68 mm × 69.3 mm (6.56" × 2.68" × 2.73")
- Approx. 296 g (0.65 lb.)
